Physical

Density

1.2

g/cm3

ISO 1183

Haze

<0.5

%

ASTM D1003

Light   Transmission

89

%

ASTM D1003

Mechanical

Tensile   Strength

60

MPa

ISO 527

Elongation

>100

%

ISO 527

Bend   Strength

91

MPa

ISO 178

Tensile   Modulus

2300

MPa

ISO 178

Surface   tension

≥34

 dyn／cm

Test fluid

Electrical

Dielectric   Constant

3

-

IEC60250

Resistant   Puncture Voltage

30

MV/mm

IEC 60243

Surface   resistivity

1.00E+16

Ω/square

IEC 60093

Volume   resistivity

1.00E+17

Ω-cm

IEC 60093

Thermal

Coefficient   of Thermal Expansion

5.8

×10^-5/℃

ISO 11359

Thermal   Conductivity Rate

0.2

W/(m*K)

ASTM D5470

Thermal   Shrinkage

0.5～0.7

%

ASTM D1204

Tg

152

℃

ISO306

Flammability

Grade of   resistant flame

V-0

           E249605

Thickness
mm

Width×Length
mm×mm

 Thickness
inch

 Width×Length
foot×foot

0.80

915×1220

0.0315″

3′×4′

915×1830

3′×6′

1000×2000

3.3′×6.6′

1220×1830

4′×6′

1220×2440

4′×8′

1.00

915×1220

0.0400″

3′×4′

915×1830

3′×6′

1000×2000

3.3′×6.6′

1220×1830

4′×6′

1220×2440

4′×8′

1.50

915×1220

0.0600″

3′×4′

915×1830

3′×6′

1000×2000

3.3′×6.6′

1220×1830

4′×6′

1220×2440

4′×8′

2.00

915×1220

0.0800″

3′×4′

1220×2440

4′×8′

2.50

915×1220

0.1000″

3′×4′

1220×2440

4′×8′

3.00

915×1220

0.1200″

3′×4′

1220×2440

4′×8′

4.00

915×1220

0.1600″

3′×4′

1220×2440

4′×8′
